Hello, and welcome back to The 8-Bit Guy.
So, in this episode, what I'm going to be doing is a complete restoration of this IBM
PC jr.
Now, this was recently donated to me by Sean Hafeez, and it's actually not in bad shape,
but it actually does have a problem with the monitor and the keyboard.
So, let's see what we can do to fix it up!
Looking at this system, cosmetically it is in pretty good shape and just needs some minor
cleaning.
But the keyboard is noticeably yellowed compared to the computer.
It also has some nasty gunk between the keys, which shouldn't be too hard to clean, but
it is also missing the little silver badge.
The monitor is a different story.
As seen here in the original unboxing video, the monitor doesn't work, even though it
was working before Sean shipped it.
Since the PCjr has a proprietary video connector, there was no easy way to test this monitor
on another system, so I plugged in a composite monitor to the PCjr to verify the computer
was working.
After that, I took the monitor partially apart to look for anything loose, but couldn't
find anything.
Eventually, I discovered that if I whacked the side of the monitor, it would come on
for a short time, but the picture was unstable.
So we'll come back to the monitor later.
For the moment, let's have a look at the keyboard.
This thing has a lot of black scuffs on it, some that don't show up well on camera.
So, I'm going to use one of my tried and true methods, where I just put some baking
soda on a paper towel and then wet it with water until it becomes kind of a mushy paste.
This works extremely effectively on this keyboard.
Here's one on the side that wouldn't come off easily with windex or alcohol.
And it just wipes away in seconds with baking soda.
Once I'm happy with the exterior, I decided I should open it up, for a number of reasons.
For one, it will make it easier to clean the keys, but also I want to retrobrite this thing.
While removing the screws on the bottom, I also noticed that it has these little rubber
feet here, and one there, but it is missing this one.
So I will have to find or fabricate a replacement.
Despite removing all of the screws, I couldn't get the keyboard open.
Feeling around on this label, it felt like maybe there was a hidden screw under there.
And sure enough, there it is.
After removing that, it opened up easily, and oops..
I forgot to take the batteries out of this thing.
Ok, here's the circuit board, and here's the little rubber contact mat, which appears
to also double as a spring for each key.
This thing is pretty filthy and will need to be cleaned up as well!
I wasn't sure how the keys came out at first.
Looks like the space bar comes out easily enough, as does the enter key.
It appears the keys just pop off with some force like this.
So, I thought maybe I should get out my key puller and use that.
And while that does work, it occurred to me that it might be easier just to push them
out from the other side.
And that works fine too.
The easiest way to clean this mat was just a good spray with the hose.
Then I gave the keyboard a good spray as well.
And here they are.
They aren't fully dried off yet, but you should already be able to tell a big improvement
there.
Although, it's interesting how it has this discoloration now.
And plastic seems much improved as well.
OK, so this is a little bit of a mystery before I start the retrobrite.
If you look at the actual PC junior's case color and compared to say, this space bar,
the color matches perfectly already.
I see no reason to attempt to treat these keys at all.
But, when you compare to the keyboard case itself, the keyboard is noticeably more yellow
than the computer.
I think it may be less visible on camera, but there is clearly a difference in person.
But here's where things get interesting.
The inside of the keyboard is essentially the same color as the outside.
This typically indicates that this may be the original color of the keyboard because
UV light damage willl usually just affect the outside.
So, I am not 100% sure if what I'm about to do will change it any.
But I do know I want to take some alcohol and remove the residual adhesive from this
little badge area here, because I plan to fabricate a new badge.
And it looks like alcohol did the job for that.
Now, all of the keys on this thing are dirty, but 4 or 5 of them have this really sticky
gunk on them like this.
I tried using windex, and later alcohol and neither one made a dent.
However, I found that I could use my fingernail to carefully scrape the gunk off.
After that, alcohol removed what residue was left.
And this is the finished key.
So, now just to do the rest of the keyboard.
Since the keyboard is fairly small, and to avoid any streaking, I decided to use the
submersion method on it.
I filled up a small bucket of water, just deep enough for the keyboard.
And one concern I had was that the back of the keyboard had a lot of air pockets and
I wasn't sure if it would sink or not.
Fortunately, it did.
I'll be using the clear salon developer liquid.
And then I'll let this sit out in the sun for a few hours.
And while that's going, I thought I'd turn attention to the monitor problem.
OK, so, for the CRT part of this problem, I thought I would enlist some help.
So, I know my way around a CRT a little bit, I've done videos on CRTs before, but I am
by no means an expert, and so I thought I would ask DJ here, who lives in town, he also
runs a YouTube channel doing all kinds of old retro computer junk too, so I'll put
a link down in the description.
Anyway, he knows a little more about CRTs than I do so he's going to help me out with
this.
Hey y'all, I'm DJ and I'm not an expert with monitors either but I've had a lot
of experience with them over the years and I've learned a lot from one of the modern
experts in CRTs.
And there's only a few things that are probably wrong with this thing given what its doing
right now.
And the one thing that I think we're probably looking at here is something to do with the
flyback transformer.
This monitor was working before it got shipped here and upon arrival it was intermittent
or non functional.
And typically what this means is that the flyback transformer, which is a big heavy
part mounted on top of a PCB probably had some rough handling of the entire monitor
during the shipping.
It's a miracle these days that you can ship a CRT and have it arrive in one piece.
But, with that flyback transformer getting jostled around it's quite possible that
it's broken solder joints or possibly cracked a trace on the PCB and so, what we really
need to do is just kind of open it up and see what we're working with and see if we
see anything that stands out.
So, DJ got to work disassembling the monitor.
Of course, I had already done this myself but hadn't gone any deeper than than just
taking the cover off.
So, let's turn it on here and see what happens.
Hey!
We got high voltage!
So, we already knew that that was intermittent.
But, what I wanted to turn it on for was to check and see if we could tell that the heater
was glowing.
And I do see the heater glowing.
Just faintly.
I actually had to turn the lights out in the room and make it completely dark before the
camera was able to really see the heater glowing.
Well, that tells us that the heater is not the problem.
I just wanted to see if the heater was going to come on, but we got high voltage this time,
so something changed regarding the orientation of the machine, or us banging around on it
trying to get it disassembled.
All right, so when we had it face down and we were working on it, we noticed it was turning
on every single time that we tried to turn it on and had a picture every time.
And then, we flipped it down to this orientation and it stopped having any high voltage.
If I turn it on at this point, it kind of goes whit, but it doesn't make any high
voltage.
But, if I flex the board, it comes on.
And so I suspect we've got either a bad solder joint or a broken trace.
So, even though I don't think this thing is charged any high voltage, I want to make
sure the tube is discharged before we mess around with it too much more.
So I will hook onto the DAG ground there.
So this screwdriver is now grounded.
And we just get it up under the cup.
And there was no curpaps.
So, it's not charged.
All safe.
After discharging, DJ started to disconnect all of the cables so that the boards could
be removed and examined more closely.
During manufacturing they had placed a big blob of what looks like some kind of silicone
like they use for windshield sealant.
Anyway, we couldn't get it loose so DJ just sliced it off with his knife.
Finally, we had all of the boards disconnected.
OK, so we noticed this from the other side as we were disassembling it and we suspected
that there was a crack, but here is a big ole crack that goes clear over to here.
And it cuts, it possibly cuts through this trace, definitely cuts through this trace
cuts all the way across this solder joint, then there's this gap here, an air gap for
this transistor, but on the other side of it, it continues across here and cuts through
this trace, and possibly this trace and maybe into this one.
So, we just need to investigate that and see what we need to bridge out there.
Since this crack might be hard to see for some of you, I thought I'd get the magnifying
glass out and let you see a bit more closeup what we're dealing with here.
And I created this little diagram so you could see exactly where the crack is and how much
of the board it covers.
As bad as this looks, it doesn't actually cross that many traces so, this could have
been a lot worse.
OK, so the first two that we're going to tackle are this one right here, which we can
actually, if you get into it with the magnifying glass you can see that there's a crack right
through the middle of that hole, but all we need to do is reflow that joint to make it
whole.
This one here, though, we need to get in here and scrape away some of the solder mask on
either side of this crack, so that we can make a bridge across the crack.
I'm using a very high tech tool here, its called my pocket knife.
I just want to expose enough copper here that we can do that bridge.
Next, DJ added a little solder to the copper he had exposed, then he bent a paperclip to
an approximate size and soldered it right across the crack.
Then he just chopped off the extra paper clip, and the joint is repaired.
OK, so then I just want to make sure that this joint that we just made has continuity
so I'll go here and the meter says yes.
After that, we worked to re-assemble the monitor, which took about 20 minutes.
The whole time we were crossing our fingers and hoping this fixed everything.
We had to cut several zip ties, so we replaced those with brand new zip ties.
We also used some hot glue to fill in that area we had to cut away before.
Well, let's see if we let the smoke out or if it blows up or something like that.
We've got it all put back together again.
Hoping for the best.
Hey, I hear high voltage.
Look at that!
I'm going to poke at it now.
Still got high voltage.
Alright!
I'm calling that one fixed!
OK, it's been a few hours, so time to check on the keyboard!
I've got to admit I can't see any difference, but it's hard to say until I rinse it off
and take it inside to compare with the PCjr.
So here it is after rinsing and comparing it with the other half of the keyboard, I
can't actually see any color difference.
So, I think this is the original color after all.
That being the case, it is time to put the keys back in.
Fortunately, I do have a picture I took of the keyboard before I started, which will
make it easier to re-assmble.
Popping keys back into a freshly cleaned keyboard is always extremely satisfying.
It's like you just bicycled up a really tall hill and now you are coasting back down
the other side.
And here's the freshly cleaned rubber mat.
And the logic board.
And the back piece.
And here's the finished keyboard.
The color may not have changed, but it looks a hundred times cleaner now!
It looks almost brand new, except for one problem, which is that missing badge.
So I had an idea of how to solve this.
Looking at the PCjr itself, I assumed the badge probably matched this one.
They are the same size.
I think I can use my brother label maker to print a replacement.
I always keep several different colors in stock for this sort of thing.
I think I'll use the black text on clear background.
So, I'll pop this one into the label maker, then I made a quick little design here.
Since the labels aren't wide enough, I made it as two separate parts.
And now to print it.
Of course to make this look right, I want to stick the labels onto this aluminum tape.
So I first had to cut a square that fit perfectly in the hole.
And once I was sure it fit, then I peeled the backing off the label like so, and I think
you can see where I'm going with this.
I just stuck this right to the aluminum.
And here's the finished badge.
Granted, this is much thinner than the original badge.
But I think it will still stand up to scrutiny in most cases.
And there we have it.
It's obviously not perfect, but it was easy to make and I would imagine the average person
would never notice that it wasn't the original.
I went to the hardware store to find rubber feet, but it's hard to know which one will
fit.
As I'm always needing rubber feet in various sizes and I'm just about out of them anyway,
I just bought one of each package.
I'll likely use these at some point in the coming years.
This keyboard uses unusually small rubber feet.
I tried the smallest one I got and it was still too large.
What I'll do is order some smaller ones on eBay, but for the moment I can just cut
these down to size and they should fit just fine.
And so yeah, there you go.
Fits fine now.
However, there's still a problem in that the new foot is slightly taller than the rest,
especially this one on the opposite end.
So what I'll do is go ahead and pull that one out too, and replace it with another of
the same kind.
And then I'll turn it over and test it out.
Yep, it is not wobbly anymore.
As for the computer, it still needed to be cleaned, but it was mostly just scuffs and
dirt, so I just used my usual methods to clean it up.
Once I was done cleaning, I thought I'd better go ahead and do some disk drive maintenance.
I used some alcohol and cleaned the disk drive heads.
This one is double sided, so you have to clean top and bottom.
Then I used some lithium grease on all of the moving parts, especially the rails.
And now it's time for a final test.
The computer looks good.
And it appears to be working properly as well.
This restoration project has been a complete success, unlike some of my earlier projects.
All right guys, I hope you enjoyed this episode on restoring the PC Junior.
This is one of my more successful restoration projects.
And I always want to give a thanks out to DJ for helping me with this monitor.
There is something that I want to mention, though.
First of all, this video was not planned, I just needed to get it done because I am
planning on doing an entire documentary on the PC Junior here relatively soon.
So, I just needed to get it working.
The other thing that I wanted to mention is because I am using a CRT display in this video,
I just thought this would be a good opportunity to mention a problem that pops up from time
to time.
I always get comments down in my videos saying, "Hey David, can't you remove that terrible
high pitched whine noise that I hear, it hurts my ears."
Well, here's the thing.
Actually, I do.
In fact, 95% of the time I get that whine removed, but 5% of the time I don't.
And you're hearing the 5% of the time that I've missed it.
The reason I missed it is because my 42 year old ears simply can't hear the sound, at
all.
Now, I know what the sound sounds like because I remember hearing it when I was younger.
So, what I have to do is I have to look for any scene where I'm using a CRT and then
I can actually dump a high pitched filter in there in the editing process to hopefully
reduce or remove that sound.
But, here's the thing.
When I'm done with a video, I typically watch it two or three times looking for spelling
mistakes, or you know anything wrong with like where something needs color correction
or something like that and I can see those things most of the time when I'm reviewing
the video.
But, I literally can't hear the high pitched whine so if I've missed it then I've just
missed it.
So, all I can do is apologize for that, hopefully I got it all in this video, I tried.
I went back like three times and verified every clip that has a CRT in it.
I put the filter on there.
Sometimes the filter doesn't always work too.
I'm not sure why, but I've been told sometimes they can still hear it even when I know I've
put the filter on there.
So, I hope I got it all out, maybe I didn't.
Anyway, I'll apologize for it in advance.
And, I look forward to presenting the full documentary on this computer.
It's a really fascinating piece of computer history.
Until then, stick around and thanks for watching!
For more infomation >> Mẹo Chơi Bầu Cua Bịp Không Bao Giờ Thua - Lac Bau cua Tom ca Trên Điện Thoại - Duration: 8:04.
For more infomation >> 【subnautica】元水泳部がお届けするサブノーティカ ふーどの人のゲリラ放送(ふーどの部屋)#5 - Duration: 54:11.
For more infomation >> How to Invest for Beginners - 2 Things You Must Do Before You Invest - Duration: 2:57.
For more infomation >> Gov. Bevin says America must address its 'culture of death' - Duration: 6:00.
For more infomation >> Deputies search car in protective suits - Duration: 0:58.
Không có nhận xét nào:
Đăng nhận xét
